VigilLink

VigilLink VLHA-DWM HDMI 2.0 18Gbps 4K2K 50/60Hz Audio Downmixer - HDMI 2.0b / HDCP 2.2 and DVI Compliant

SKU VLHA-DWM
$196.00
$196.00
VGL-VLHA-DWM:

Estimated shipping time

You can typically expect your items to arrive within 4–7 business days, depending on your location and product availability.

What is your Return Policy?

At Electra Casa, we want every customer to shop with confidence. If something doesn’t go as planned, we’ve made returns and refunds simple and fair. Here’s how it works:

1. Return Window

You can request a return within 30 days of receiving your order. Unfortunately, we’re unable to accept returns after that time frame.

2. Who Pays for Return Shipping?

  • If your item arrives damaged, defective, or incorrect, we’ll cover the return shipping cost.
  • If you’re returning an item because you changed your mind, you’ll be responsible for return shipping fees.

3. Damaged or Defective Items

Received something broken or not working properly? Contact us within 30 days. We’ll provide a prepaid return label and once the item is returned and inspected, we’ll issue either a full refund or a replacement—including any original shipping costs.

4. Changed Your Mind?

If you no longer want the item, you can return it within 30 days—as long as it's unused, in its original packaging, and in resellable condition. You’ll need to handle the return shipping, and once we receive and inspect it, we’ll refund the product cost (excluding shipping).

5. Refund Processing

Once we receive and approve your return, we’ll send a confirmation email and issue a refund to your original payment method within 7 business days. Please allow additional time for banks or credit card companies to process and reflect the refund.

If it’s been over 10 business days since your refund was approved and you still don’t see it, contact us at support@eectracasa.com and we’ll look into it immediately.

6. Restocking Fees

In some cases, a restocking fee may apply depending on the item and return reason. If applicable, we’ll clearly communicate this during your return request process.

The VigilLink VLHA-DWM HDMI 18Gbps Audio Extractor could extract audio signals from any HDMI-compliant source to digital optical or analog stereo L/R audio outputs. For maximum flexibility, this audio extractor also supports bitstream audio down-mix to analog stereo output and keeps optical and HDMI out audio pass-through. Further, both input and output HDMI support video resolution up to 4K2K@50/60Hz (YUV444). It supports 10bits HDR (High Dynamic Range) pass-through and HDMI high-resolution digital audio formats bypass, LPCM 2CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos, and DTS-HD Master Audio, with audio sampling rates up to 192 kHz. HDCP 2.2 and CEC bypass are supported.

Features:

  • HDMI 2.0b (18Gbps), HDCP 2.2, and DVI compliant
  • Video resolutions up to 4K2K@50/60Hz (YUV444)
  • Extract HDMI audio to multi-channel optical (SPDIF) or L/R analog audio
  • HDMI Pass-through audio input to HDMI and optical audio output
  • Supports bitstream audio down-mix to L/R analog output
  • Optical audio supports LPCM 2CH, Dolby Digital 2/5.1CH, DTS 2/5.1CH
  • Supports HDMI High Bit Rate (HBR) audio pass-through
  • Audio sample rates up to 96kHz
  • 10bits HDR (High Dynamic Range) pass-through
  • Supports CEC pass-through

Specifications:

Technical

  • HDMI Compliance: HDMI 2.0b
  • HDCP Compliance: HDCP 2.2 and HDCP 1.4
  • Video Bandwidth: 18Gbps
  • Video Resolution: Up to 4K2K @ 50/60Hz (YUV4:4:4), 4K2K @ 30Hz, 1080p @ 120Hz, and 1080p 3D @ 60Hz
  • Color Depth: 10-bit, 12-bit
  • Color Space: RGB, YCbCr 4:4:4, YCbCr 4:2:2
  • HDMI Audio Formats (Pass-through): LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X
  • Optical Audio Formats: LPCM 2CH, Dolby Digital 2/5.1 CH, DTS 2/5.1CH
  • L/R Audio Formats: Analog Stereo 2CH
  • ESD Protection: Human-Body Model: ±8kV (Air-gap discharge), ±4kV (Contact discharge)

    Connection
  • Inputs: 1x HDMI Type A (19-pin female)
  • Outputs:
  • - 1x HDMI Type A (19-pin female)
  • - 1x L/R Audio Out (RCA)
  • - 1x Optical Out (S/PDIF)

    Mechanical
  • Housing: Metal Enclosure
  • Color: Black
  • Dimensions: 2.90" x 2.39" x 0.79" (73.5mm x 60.7mm x 20mm)
  • Weight: 0.30lbs (135g)
  • Power Supply:
    - Input: AC 100V - 240V, 50/60Hz
    - Output: DC 5V/1A (US/EU standards, CE/FCC/UL certified)
  • Power Consumption: 1.25W (Max)
  • Operating Temperature: 32°F - 104°F (0°C - 40°C)
  • Storage Temperature: -4°F - 140°F (-20°C - 60°C)
  • Relative Humidity: 20% - 90% RH (No condensation)

Item Includes:

  • 1x HDMI 18Gbps Audio Extractor
  • 1x 5V/1A Power Adapter
  • 1x User Manual

Warranty:

  • 6 Years
